VADI Nebulizer & Accessories
Part Number
- VC04-01
Features
VADI Nebulizer is intended for use by children and adults undergoing respiratory therapy in hospitals according to the physician’s order.
During use, the pharmaceutical type, dosage, and frequency should be applied exactly as prescribed by a professional physician. To treat respiratory tract diseases, a vibrating mesh plate is used to aerosolize the liquid medicines, which are subsequently delivered to the patient’s upper and lower respiratory tracts through the nasal and oral cavity.
Specifications
|
Item |
Specification |
|
Model No. |
VC04-01 |
|
Operating Principle |
Vibrating Mesh Plate |
|
Vibrating Frequency |
120kHz ±20% |
|
Maximum Capacity of the Nebulizer Cup |
6 ml |
|
Residual Volume |
＜0.1 ml |
|
Mass Median Aerodynamic Diameter (MMAD) |
＜5μm |
|
Aerosol Output |
＞0.6 mg |
|
Aerosol Output Rate |
＞0.07 mg/min |
|
Alarm Sound Pressure Level |
＜30 dB |
|
Ingress Protection Rating of the Controller |
IP22 |
|
Input Power |
5VDC / 0.5A |
|
Consumption Power |
10W |
